ASTM A193 B7 B7M Black Stud Bolt

Gangtong Zheli is ASTM A193 B7 B7M Black Stud Bolt manufacturers and suppliers in China who can wholesale it.
Production technology: Cold forging and hot forging, Lathe
Min Order: 500KG each size
Sample: Free sample
Certificate: MTC, Test report
Export country: Asia, Middle East, Europe, America and so on

Send Inquiry

Product Description

Gangtong Zheli is China manufacturer & supplier who mainly produces ASTM A193 B7 B7M Black Stud Bolt with many years of experience. Hope to build business relationship with you. A stud bolt, also known as a threaded rod or simply a stud, is a long rod with threading on both ends, and the threading can extend along its entire length. Stud bolts are primarily designed to be used in tension, providing a secure connection in various applications. When threaded rods are in the form of bar stock and feature threads along their entire length, they are commonly referred to as all-thread. Studs may have a drive slot on one end, making it easier to install them in place. There are two main types of studs based on their threading configuration: full-bodied studs and undercut studs. Full-bodied studs have a shank that matches the major diameter of the thread, while undercut studs have a shank that corresponds to the pitch diameter of the screw thread. Undercut studs are designed to distribute axial stresses more effectively, reducing the stress concentration found in the threads of full-bodied studs.


ASTM A193 is a specification that covers a range of materials, including alloy steel and stainless steel, for use in pressure vessels, flanges, pipes, fittings, and other components subjected to high temperatures, high pressures, or special applications. This standard includes several grades, such as ferritic steels and austenitic stainless steel, tailored for specific requirements. Material conforming to ASTM A193 B7 is often used with national coarse (UNC) thread pitches and standard thread pitches in various applications where high-strength fasteners are needed.



ASTM A193 B7 B7M Black Stud Bolt


Tech.Standards Material Grade Size Finish
Thread rod DIN/ASTM 1008

GB Standard 4.8

Grade ASTM

Standard Grade2

M2-M120
1/2-5"
ZINC,HDG,Black
Hs3404 ASTM193/A193M

GB Standard
40Cr 35CrMo

25CrMoVA
0Cr18Ni9,

0Cr17Ni12Mo2

etc ASTM

standard
Alloy and

tainless steel

GB standard
Grade8.8,10.9,

12.9 A2-70,A4-70
ASTM Standard
B5,B7,B7M,B8,

B8M,B16 L7,

L7M,

BC,BD,660A,

660B,651A,651B

GBstandard
M12-M120
ASTM Standard
1/2-5"

Black,zinc plated

HDG,Cadmium
Plated, Dacromet,

Passivation
Teflon(PTFE,FEP

PFA ETFE)

HG/T20634 ASTM320/A320M
HG/T20613 ASTMA354
JB/T4707 ASTMA453
SH3404 ASTMA194/194M

GB Standard
40Cr,35CrMo,

25CrMoVA,

0CR18Ni9,45#,

0Cr17Ni12Mo2
ASTM Standard
Alloy and

stainless steel

GB Standard
Grade8,10,

A2-70,A4-80

ASTM Standard

660A 660B 651A,

651B 2H,2HM,4,

6.7,8,16O,A,B,C,

D,DH

GB or DIN

standard
M12-M120
ASTM Standard
1/2-5"

Black,zinc plated

HDG,Cadmium
Plated, Dacromet,

Passivation
Teflon(PTFE,FEP

PFA ETFE)

HG/T20613 ASTMA563/563M
HG/T20634
HG/T21573.3
Get Free Samples for standard fastener from Gangtong Zheli Fastener


ASTM A193 B7 Material and Chemical Composition:


ASTM A193 B7 Alloy steel, AISI 4140/4142 quenched and tempered
ASTM A193 B8 Class1 stainless steel, AISI304, carbide solution treated
ASTM A193 B8M Class1 stainless steel, AISI316, carbide solution treated


Application:


Project to fasten.
